Post Info TOPIC: 1938 Chev


New Member

Status: Offline
Posts: 3
Date:
RE: 1938 Chev
Permalink



Nice work on the 36. I plan on building a 36 when i finish my 57 :)

Keep the pics coming. Maybe ill see this 36 rolling around town this summer :)

__________________

Bellville,Ottawa

1957 Belair C4 suspension.

1930 Model A Rat Rod project buddies



BELLEVILLE, ONT

Status: Offline
Posts: 959
Date:
Permalink


Made up some rear body mounts and got them welded in. A piece of 16 gauge cut bent and welded. These will go in at the very back where the floor meets the tailpan.


Bolted in and shimmed the body to cut the rest of the floor out.


With all the old out, time to start  making new panels. First is the new right side inner wheel tub.


Started with a cardboard template. Traced to a piece of 18 gauge, Bottom edge is rolled under and flatted. Inner raised panel done on bead roller. Top flange bent 90 degrees.









Attachments
__________________

Custom CNC plasma cutting. PM me for your custom parts.

www.lightspeedmetaldesign.com



BELLEVILLE, ONT

Status: Offline
Posts: 959
Date:
Permalink




Had to stop on the body work for now cause next was the trunk floor. Can't build it till the fuel tank was installed. Can't install tank till it's built.

With some cutting, bending and a whole pile of welding I have a 18 gallon fuel tank out of aluminum. It's about 9.5" X 36" X 13" high. Had to build it this way to accept the fuel pump assembly.





Attachments
__________________

Custom CNC plasma cutting. PM me for your custom parts.

www.lightspeedmetaldesign.com



PORTLAND, ONT

Status: Offline
Posts: 262
Date:
Permalink


HI MIKE : Your workmanship is still outstanding -- Keep it up and keep the pics coming -- THANKS -- LATER -- DON / Fleet 51

__________________


BELLEVILLE, ONT

Status: Offline
Posts: 959
Date:
Permalink



Finally got around to plucking the donor driveline out. Pulled a valve cover off and was very pleased to find it spotless inside. The truck had 292,000 KM, so it must of been well maintained. Removed as much wiring harness as I could, under hood, under dash and to the fuel tank. Will start stripping it some time.


Tossed it in the frame, leveled and squared. Tack welded a 2X2 tube to the bottom of the frame to hold the trans up and shim it to location. Started to make engine mounts. I had already made up the block mounts, just a matter of locating the engine and making some tabs to the frame.








Attachments
__________________

Custom CNC plasma cutting. PM me for your custom parts.

www.lightspeedmetaldesign.com



BELLEVILLE, ONT

Status: Offline
Posts: 959
Date:
Permalink


Got the car together and managed to put 5000 km om it last year. Drove great, a few bugs to work out.
Torn it apart to start painting, got the dash painted and reassembled, very happy with the result.








Attachments
__________________

Custom CNC plasma cutting. PM me for your custom parts.

www.lightspeedmetaldesign.com



MARKHAM, ONT

Status: Offline
Posts: 1334
Date:
Permalink


Nice.

__________________
PUGSY


DOURO, ONT

Status: Offline
Posts: 987
Date:
Permalink


nice

__________________

1947 Ford convertible, 73 Javelin drag car, 1953 Mercury pickup, 1963 F100 Unibody 4x4



PRINCE EDWARD COUNTY, ONT

Status: Offline
Posts: 1278
Date:
Permalink


Wouldn't expect anything less.
Warren

__________________
You can only make it better


FOXBORO, ONT

Status: Offline
Posts: 2226
Date:
Permalink


Looking good Mike, if you need an extra pair of hands for anything don't be shy to ask bud.

__________________
if your not the lead dog-the view is all the same


BELLEVILLE, ONT

Status: Offline
Posts: 959
Date:
Permalink


shag766 wrote:

Looking good Mike, if you need an extra pair of hands for anything don't be shy to ask bud.


 Thanks Rick, you're welcome over anytime. Just give me a call or text to make sure I'm home.





__________________

Custom CNC plasma cutting. PM me for your custom parts.

www.lightspeedmetaldesign.com
